Complete range of Mundus Fluid UV-C water disinfection systems from compact to industrial scale

    Our Products

    UV disinfection systems from 2 m³/h to 250 m³/h

    Developed, designed and manufactured in Germany. Highest quality for industrial requirements.

    DW100-01 UV-C disinfection system – 2-10 m³/h flow capacity, 1 UV lamps

    DW100-01

    Compact UV disinfection system for smaller flow rates. Ideal for drinking water treatment in residential buildings and small businesses.

    Flow Rate
    2-10 m³/h
    UV Lamps
    1
    Connection
    DN25
    Dimensions (HxWxD)
    1200 x 800 x 500 mm
    Best Seller
    DW300-04 UV-C disinfection system – 20-60 m³/h flow capacity, 4 UV lamps

    DW300-04

    The all-rounder: UV disinfection system for medium flow rates. Ideal for hotels, hospitals and car washes.

    Flow Rate
    20-60 m³/h
    UV Lamps
    4
    Connection
    DN30-DN65
    Dimensions (HxWxD)
    1664 x 1209 x 625 mm
    DW300-06 UV-C disinfection system – 40-80 m³/h flow capacity, 6 UV lamps

    DW300-06

    Powerful UV disinfection system for larger flow rates. Optimized for industrial process water applications.

    Flow Rate
    40-80 m³/h
    UV Lamps
    6
    Connection
    DN50-DN80
    Dimensions (HxWxD)
    1800 x 1300 x 700 mm
    DW500-12 UV-C disinfection system – 100-250 m³/h flow capacity, 12 UV lamps

    DW500-12

    High-performance UV disinfection system for maximum flow rates. The choice for large industrial plants and critical processes.

    Flow Rate
    100-250 m³/h
    UV Lamps
    12
    Connection
    DN100-DN150
    Dimensions (HxWxD)
    2200 x 1600 x 900 mm
